Guidance and Manufacturer’s Declaration cont.
Guidance and Manufacturer’s Declaration—Electromagnetic Immunity
This Medical-Grade UPS is intended for use in the electromagnetic environment specified below. The
customer or the user of this Medical-Grade UPS should assure that it is used in such an environment.
Immunity Test IEC 60601 Test Level
Compliance
Level
Electromagnetic
Environment - Guidance
Electrostatic Discharge (ESD)
IEC 61000-4-2
+ / - 6kV contact
+ / - 8kV air
Complies Floors should be wood,
concrete or ceramic tile. If
colors are covered with
synthetic material, the
relative humidity should be
atleast30%.
ElectricalFastTransient/Burst
IEC61000-4-3
+ / - 2kV for power supply
lines
+ / - 1kV for input/output
lines
Complies Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
+ / - 1kV differential mode
+ / - 2kV common mode
Complies Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage dips, short
interruptions and voltage
variations on power supply
input lines
IEC 61000-4-11
<5%U
T
(>95%dipinU
T
) for .5 cycle
40%U
T
(60%dipinU
T
) for 5 cycles
70%U
T
(30%dipinU
T
) for 25 cycles
<5%U
T
(>95%dipinU
T
) for 5 seconds
Complies Mains power quality should
be that of a typical
commercial or hospital
environment.
PowerFrequency(50/60Hz)
Magnetic Field
IEC61000-4-B
3A/m Complies Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Note:U
T
is the AC mains voltage prior to application of the test level.
Overcurrent Protection
The unit is equipped with 2 20A, branch-rated, circuit breakers.
Battery Pack
The unit comes with a 48VDC, rechargeable sealed lead-acid battery pack rated at 9 amp
hours.Yourbatteryshouldlastforseveralyears.Ifneeded,replacementbatterypacksforthis
UPSareavailablethroughTrippLite,modelnumberRBC48V-HGTWR.
