General Information
10 800092-01 Rev. A www.wegener.com
Physical Characteristics
Table 1.14: iPump 562 Physical Characteristics
1.4 Safety Summary
The iPump 562 is designed for safe use with few special precautions required of the user.
The following items are basic precautions to use when installing and working with the
iPump 562 unit:
Do not open the iPump 562's chassis cover.
The iPump 562 incorporates security labels over some of the screws. There are no user
serviceable components within the IRD. Tampering with the security labels, or opening the
unit, will void your warranty. If you have questions, contact the
WEGENER Customer
Support Department
at the address or phone (fax) numbers listed in Chapter 5 Customer
Service, of this manual.
Physical Characteristics
Chassis Height 1 RU for desktop - 1RU using supplied rack ears
Chassis Width 16.5 inches - with optional rack ears - 19 inches
Chassis Depth 11.5 inches
Weight 7.5 lbs.
Front/Rear Panel Labeling
Chassis Finish Silver powder-coat, fine texture
Rear-panel silk-screen color Gray lettering per PMS-427C
Front Panel Plastic snap-on bezel with 5 button switches embedded
in label
