48 800092-01 Rev. A www.wegener.com
Apx 1.2 Diagterm Individual Commands
The diagterm individual commands are not grouped together under common groups. These
commands perform functions such as setting audio attenuation or turning on LNB power.
groups Report List of Groups
Group Name: rdbs
Command Synopsis
report Report RBDS Status
test Send test message to RBDS port "test <port> <message>
Group Name: lan
Command Synopsis
ip Set Static LAN IP Address of the Unit
gateway Set Network Gateway for LAN Interface
mode Set LAN Addressing Mode (DHCP, STATIC,WEG)
setup Set IP Address and Subnet mask for the LAN port
subnet Set static LAN subnet mask
Group Name: output
Command Synopsis
aspect Set output aspect ratio of the display device 4x3;16x9;14x9
cc Set closed captioning mode [tv|cc1|cc2|cc3|cc4|dtv]
scaling Set output display scaling mode [letterbox|panscan]
Group Name: sigma
Command Synopsis
ver Print version information
Group Name: http
Command Synopsis
proxy Set the proxy server for http
Group Name: snmp
Command Synopsis
community Set SNMPV2 Community Access String
