23.4 IGMP Snooping VLAN
Click Advanced Application > Multicast > IPv4 Multicast in the navigation panel. Click the
IGMP Snooping link and then the IGMP Snooping VLAN link to display the screen as shown. See
Section on page 162 for more information on IGMP Snooping VLAN.
Figure 122 Advanced Application > Multicast > IPv4 Multicast > IGMP Snooping > IGMP Snooping
VLAN
IGMP Querier
Mode
The Switch treats an IGMP query port as being connected to an IGMP multicast router (or
server). The Switch forwards IGMP join or leave packets to an IGMP query port.
Select Auto to have the Switch use the port as an IGMP query port if the port receives
IGMP query packets.
Select Fixed to have the Switch always use the port as an IGMP query port. Select this
when you connect an IGMP multicast server to the port.
Select Edge to stop the Switch from using the port as an IGMP query port. The Switch will
not keep any record of an IGMP router being connected to this port. The Switch does not
forward IGMP join or leave packets to this port.
Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top navigation
panel to save your changes to the non-volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Table 68 Advanced Application > Multicast > IPv4 Multicast > IGMP Snooping (continued)
LABEL DESCRIPTION
