Chapter 10. Dedicated Maps
61200305L1-1 ATLAS 550 User Manual 10-3
C
REATE
/E
DIT
M
APS
Creates new maps and defines settings, as well as edits existing maps. To
add a new map, position the cursor in the index column and press I.ATLAS
550 automatically names the maps in the sequence in which they are created;
however, this sequence can be sorted (see the subsequent discussion of Sort
TO/FROM). You can change the names with M
AP
N
AME
.
MAP NAME
Write security: 3; Read security: 5
Displays the name of the dedicated map. The name can contain up to 57
alphanumeric characters, including spaces and special characters.To edit
the name, press
Enter
and type in the new name.
SORT TO/FROM
Write security: 3; Read security: 5
Specifies sort order based on the end points set in C
ONNECTS
/F
ROM
C
ONFIG
and C
ONNECTS
/T
O
C
ONFIG
.YoucanalsoturnO
FF
this option. This sort fea-
ture is helpful when you are attempting to find a particular connection in a
large connection list.
CONNECTS
Enters the dedicated map connections. Press
Enter
to activate the submenus.
# Displays the index number of the dedicated map connection. To add another
dedicated map connection, press the I key on your keyboard. New map con-
nections are numbered consecutively. To delete a connection, press
D
.
FROM S
LT
Write security: 3; Read security: 5
(From Slot) Specifies the slot to use for the FROM connection. When you
select this option, a list of all of the slots and the modules installed in the
slots displays. Pick the appropriate slot and press
Enter
.
P
ORT
Write security: 3; Read security: 5
Specifies the port to use for the FROM connection. When you select this
option, a list of ports and module types appears. Pick the appropriate port
and module type, and press
Enter
.
Some of the options available in this submenu change depending
on the type of modules selected in the FROM or TO fields.
The ATLAS 550 does not support frame relay at a DS0 rate of 56K.
