Chapter 6. System Control Terminal Menus
6-6 ATLAS 550 User Manual 61200305L1-1
RESOURCE USAGE
Read security: 5
Indicates resource use (ANALOG
, N
AILED
D
IGITAL
, P
ACKET
V
OICE
, S
WITCHED
D
IGITAL
). Data displayed in this table is dependent on the Atlas 550 configu-
ration.
D
ATA
T
ABLES
Tracks resource usage for dynamic resources throughout the system and
presents the information in a table format.
R
ESOURCE
T
YPE
Displays the system resources list.
C
URRENT
Shows the number of resources available (not in use) and the total number
of resources. If a resource is taken offline, it is not included in the total.
A
VERAGE
Shows the average number of resources available since the statistics were
last reset.
M
INIMUM
Shows the fewest number of resources available since the last reset.
0(
ZERO
)
AVAILABLE
Provides a count of the number of times the quantity of available resources
reached 0.
H
OURLY
D
ATA
Shows availability information by hour for a 24-hour period.
R
ESET
Write security: 4; Read security: 5
Activates the reset of all accumulated availability statistics.
C
ONFIGURATION
Configures the statistics displayed under data tables.
D
ISPLAY
F
ORMT
Selects the statistics display format—R
AW
D
ATA
or %.
R
ESET
M
ODE
Write security: 4; Read security: 5
Selects the mode for resetting statistics—MANUAL
, D
AILY
,orW
EEKLY
.
One HDLC resource is used by each PRI or each Packet Endpoint.
