SYSTEM LOCATION
Write security: 3; Read security:5
Provides a user-configurable text string for the location of the ATLAS 550.
This field is to help you keep track of the actual physical location of the
unit. You can enter up to 40 alphanumeric characters in this field, including
spaces and special characters (such as an underbar).
SYSTEM CONTACT
Write security: 3; Read security: 5
Provides a user-configurable text string for a contact name. You can use this
field to enter the name, phone number, or email address of a person respon-
sible for the ATLAS 550 system. You can enter up to 40 alpha-numeric char-
acters in this field, including spaces and special characters (such as an
underbar).
FIRMWARE REVISION
Read security: 5
Displays the current firmware revision level of the controller.
SYSTEM UPTIME
Read security: 5
Displays the length of time the ATLAS 550 system has been running. Each
time you reset the system, this value resets to 0 days, 0 hours, 0 minutes and
0seconds.
STARTUP MODE
Read security: 5
Displays details about the last system startup.
CURRENT TIME/DATE
(24H)
Write security: 3; Read security: 5
Displays the current date and time, including
seconds. To edit this field, place the cursor on the
field and press
Enter
. Then, enter the time in a
24-hour format (such as 23:25:30 for 11:00 pm, 25 minutes and 30 seconds),
and the date in mm-dd-yyyy format (for example, 11-05-1999). Press
Enter
when you are finished.
INSTALLED MEMORY
Read security: 5
Displays the type and amount of memory in use (including Flash memory
and DRAM).
SERIAL NUMBER
Read security: 5
Displays the serial number for the unit. The serial number of the
ATLAS 550 will automatically display in this field.
BOOT ROM REV
Read security: 5
Displays the boot ROM revision.
S
YSTEM
S
TATUS
The S
YSTEM
S
TATUS
menu provides information on the status of the unit.
Figure6-2 on page 6-4showsthe submenu functions available in theS
YSTEM
S
TATUS
menu.
