Chapter 11. Dial Plan
61200305L1-1 ATLAS 550 User Manual 11-15
DS0S AVAILABLE
Read security: 5
Indicates which DS0s of the T1 have been defined in this switched endpoint
(indicated by “! “), in another switched endpoint (indicated by “s”), or in a
D
EDICATED
M
AP
(indicated by “n”). This field is read-only. The following
characters may display in this field:
SIGNALING METHOD
Write security: 3; Read security: 5
Defines to the ATLAS 550 the type of signaling to be used across this trunk.
The signaling selected needs to match the signaling being provided by the
network (PSTN). The following choices are available:
FGD TX SEQUENCE
Write security: 3; Read security: 5
Defines to the ATLAS 550 the format in which to present the outgoing dig-
its. Choices: N
ORMAL
ifnodigitsaretobesent; ANI/DNIS to send both ANI
and DNIS; DNIS to send DNIS only; ANI to send ANI only.
FGD RX SEQUENCE
Write security: 3; Read security: 5
Defines to the ATLAS 550 the format in which to receive the incoming dig-
its. Choices: N
ORMAL
ifnodigitsaretobereceived;ANI/DNIS to receive
both ANI and DNIS; DNIS to receive DNIS only; ANI to receive ANI only.
WINK AFTER ANI/
DNIS
Write security: 3; Read security: 5
When enabled, the ATLAS 550 will transmit a wink after ANI/DNIS digits
are transmitted.
0-9 This DS0 is available. The digit that displays in this field represents
the last digit of the DS0 number.
* This port is requesting this DS0 for thisconnection, but the DS0 is not
yet activated.
! ThisDS0isusedbythisendpoint.
s This DS0 is used elsewhere in the switched D
IAL
P
LAN
.
S This DS0 is in the switched dial plan and conflicts with this endpoint.
n This DS0 is used in one or more D
EDICATED
M
APS
.
N This DS0 is in one or more D
EDICATED
M
APS
, and conflicts with this
endpoint.
• E&M Immediate • E&M Wink
• Loop Start • Ground Start
•FeatureGroupD
The ATLAS 550 converts signaling types between network and user
terminations.
