C2657M-A (7/08) 4
LOGGING ON WITH A KEYBOARD AND MOUSE
To log on using a keyboard and mouse:
1. Select the user from the User ID list.
2. Click in the Password box, and then type the password.
3. Click Log In to accept the user name and password. If the password is correct, the DVR5100 displays the main application window.
The default user IDs and passwords are as follows:
• admin: admin or 23646
• manager: manager or 6262437
• operator: operator or 67372867
• guest: guest or 48378
LOGGING ON WITH THE CONTROL PAD
Table A lists the control pad functions at login.
To log on using the control pad:
1. Turn the Jog (inner dial) to select the user name. The default user IDs and passwords are as follows:
• admin: admin or 23646
• manager: manager or 6262437
• operator: operator or 67372867
• guest: guest or 48378
Table A. Special Logon Controls
Control Pad Functions
Jog (inner dial) Cycles through the list of users (by default, the options are admin, guest, manager, and operator).
Blue function button Press to display the on-screen password keypad. (Refer to the keypad instructions in this table.)
Green function button Press to log on to the DVR5100 once the password is entered.
Red function button Press to shut down the DVR5100 once the password is entered.
When the on-screen password keypad is open…
Joystick Navigates up, down, left, and right through the keypad’s number grid.
Enter/Shift button Enters the currently selected number into the password box.
Green function button Saves the entered password and closes the keypad.
Red function button Clears the entered password and closes the keypad.
