EN Parts diagrams 153
Table 8-5 Internal components (2 of 3)
Ref LaserJet 5L
part number
LaserJet 6L
part number
LaserJet 6L Pro
part number
Qty Description
1 RB1-7109-000CN RB1-7109-000CN n/a 1 Memory Door Guide
1 n/a n/a RB2-6226-000CN 1 Guide Sheet
2 RB1-7247-000CN RB1-7247-000CN RB1-7247-000CN 1 Fuser Paper Guide
3 RB1-7344-000CN RB1-7344-000CN RB1-7344-000CN 1 AC Cable Cover
4 RF5-1509-000CN RF5-1509-000CN RF5-6222-000CN 1 Back Sheet Metal
5 RB1-7343-000CN RB1-7343-000CN n/a 1 Control Panel Cable Guide
6 RB1-7130-000CN RB1-7130-000CN RB1-7130-000CN 1 Fuser Cable Guide
7 RB1-7234-000CN RB1-7234-000CN RB1-7234-000CN 1 Cap
8 RB1-7302-000CN RB1-7302-000CN RB1-7302-000CN 1 Cap
9 XA9-0724-000CN XA9-0724-000CN XA9-0724-000CN 6 Screw, RS, M3x8
10 XA9-0855-000CN XA9-0855-000CN XA9-0855-000CN 2 Screw, RS, M3x8 (with star
washer)
11 RB1-7176-000CN RB1-7176-000CN RB1-7176-000CN 2 Mylar Guide
12 RB1-7305-000CN RB1-7305-000CN RB1-7305-000CN 1 I/O Sheet Metal
13 RB1-7307-000CN RB1-7307-000CN RB1-7307-000CN 4 Foot
501 XB4-7401-007CN XB4-7401-007CN XB4-7401-007CN 3 Screw, Tapping, Panhead, M4x10
502 XB1-1300-807CN XB1-1300-807CN XB1-1300-807CN 2 Screw, PH, M3x8
