Numerical parts list
Table A-2 Numerical parts list
Part No. Description Fig. Ref.
C3941-69001 DC Controller PCA (110 V) Exchange (5L) 8-6 3
C3941-69002 DC Controller PCA (220 V) Exchange (5L) 8-6 3
C3941-69003 Laser\Scanner (Exchange) (5L) 8-3 19
C3942-67902 Formatter (New) (5L) 8-6 2
C3942-69002 Formatter (Exchange) (5L) 8-6 1
C3991-60001 Formatter (New) (6L and 6L Pro) 8-6 2
CK-8006 Pressure Roller Grease 8-5
HB1-3418-000CN Ground Clip, Scanner (6L Pro) 8-3 20
RB1-7105-000CN Fuser Release Tab 8-3 3
RB1-7106-000CN Gear Plate (5L) 8-3 4
RB1-7107-000CN Front Gear Case 8-3 2
RB1-7109-000CN Memory Door Guide 8-4 1
RB1-7129-000CN Case Grounding Metal 8-5 8
RB1-7130-000CN Fuser Cable Guide 8-4 6
RB1-7172-000CN Grounding Spring (6L Pro) 8-7 19
RB1-7176-000CN Mylar Guide 8-4 11
RB1-7177-000CN Paper Feed Frame 8-7 1
RB1-7184-000CN Pickup Roller Bushing 8-7 5
RB1-7185-000CN Left Leg 8-7 16
RB1-7186-000CN Right Leg 8-7 17
RB1-7197-000CN Clutch 8-7 6
RB1-7199-000CN Back Grounding Clip 8-7 7
RB1-7211-000CN Input Extender 1 (5L) 8-2 1
RB1-7212-000CN Input Extender 2 (5L) 8-2 2
RB1-7223-000CN Pickup Roller Grounding Clip 8-5 1
RB1-7226-000CN Idler Roller (5L) 8-8 9
RB1-7234-000CN Cap 8-4 7
RB1-7246-000CN Pressure Roller Bushing 8-5 2
RB1-7247-000CN Fuser Paper Guide 8-4 2
RB1-7255-000CN Left Pressure Roller Housing 8-6 13
RB1-7256-000CN Right Pressure Roller Housing 8-5 12
RB1-7276-000CN Face-up/Face-down Shaft (5L) 8-9 2
RB1-7278-000CN Face-up/Face-down Switch (5L) 8-2 2
RB1-7284-000CN Delivery Roller #1 8-10 1
RB1-7285-000CN Delivery Roller #2 (5L) 8-10 2
RB1-7286-000CN Delivery Spring #1 8-10 3
RB1-7287-000CN Delivery Spring #2 8-10 4
RB1-7288-000CN Exit Roller Bushing 8-3 17
