Section 1: Printer and Troubleshooting Overview 6-5
J/P 82 6-6 simplex/duplex A4
J/P 83 6-14 simplex/duplex E5
J/P 84 6-14 simplex/duplex E6
J/P 85 6-14 simplex/duplex B6
J/P 87 6-11 simplex/duplex C8
J/P 90 6-15 simplex/duplex B9
J/P 91 6-11 simplex/duplex C8
J/P 94 6-15 simplex/duplex B8
J/P 95 6-6 simplex/duplex C3
J/P 96 6-15 simplex/duplex C5
J/P 100 6-15 simplex/duplex D4
J/P 101 6-15 simplex/duplex D3
J/P 102 6-15 simplex/duplex C4
J/P 119 6-7 simplex/duplex C9
J/P 120 6-7 simplex/duplex C9
J/P 121 6-15 simplex/duplex B6
J/P 122 6-15 simplex/duplex B6
J/P 124 6-15 simplex/duplex B6
J/P 127 6-7 simplex/duplex C9
J/P 128 6-7 simplex/duplex C9
J/P 131 6-10 simplex/duplex E6
J/P 132 6-10 simplex/duplex E6
J/P 139 6-15 simplex/duplex B6
J/P 140 6-15 simplex/duplex B6
J/P 143 6-15 simplex/duplex B6
J/P 251 6-15 simplex/duplex B5
J/P 252 6-15 simplex/duplex B5
J/P 255 6-15 simplex/duplex A5
J/P 305 6-10 duplex E3
J/P 306 6-8 duplex E2
J/P 307 6-8 duplex E3
J/P 308 6-8 duplex E2
J/P 309 6-8 duplex E2
J/P 310 6-10 duplex F3
J/P 311 6-10 duplex F3
J/P 312 6-10 duplex F3
J/P 313 6-8 duplex F2
J/P 314 6-8 duplex E2
Connector Page
Schematic
Location
J/P 315 6-8 duplex E2
J/P 316 6-8 duplex E2
J/P 317 6-9 duplex D2
J/P 318 6-6 duplex F1
J/P 319 6-8 duplex F2
J/P 320 6-10 duplex G2
J/P 321 6-10 duplex G2
J/P 322 6-10 duplex F2
J/P 323 6-15 duplex D3
J/P 324 6-15 duplex E3
J/P 330 6-15 simplex/duplex E8
J/P 331 6-15 duplex D3
J/P 333 6-15 simplex/duplex A8,
simplex/duplex D2
J/P 500 6-15 simplex/duplex A8
J/P 800 6-15 simplex/duplex E5
Connector Page
Schematic
Location
