EP Cover Removal
7-84 Removal/Replacement Procedures
EP Cover Removal
To remove the EP cover:
1 Open the front, back, and top covers.
2 Remove the fuser.
3 Remove the photoconductor and place it in its protective packaging.
4 Remove the cleaner unit.
5 Remove the operator panel. (See page 7-19).
Support Screw
EP Cover Screws
Vacuum Transport
Supports
Front Detail
