Five patterns are printed in 0.5% steps in a range of 99.00% to 101.00%.
●
A — Dark lines are visible; the value is too low.
●
B — No lines are visible; the value is correct.
●
C — Light lines are visible; the value is too high.
NOTE Select a mean value if the media advance value is different in every color. If you
have an image that uses one particular color, then set the value based on that color.
Different values between the left and right sides of the media may be caused by skew.
6. From the printed result, select the best media advance calibration value.
7. Press the
key, and then the OK key to display the current media advance calibration value.
8. Enter the media advance calibration value, and press the OK key.
Select the number you want to change by using the
and keys and change the numeric value using
the
and keys.
If you need more precise media advance calibration, then you will need to print the DETAIL pattern
as follows:
9. Press the
key, and then the OK.
10. Press the and keys to select the DETAIL pattern.
Select the same print mode as for the ROUGH pattern you printed previously.
11. Press the OK key twice to print the DETAIL pattern.
12. From the printed result, select the best media advance calibration value.
Five patterns are printed in 0.10% steps in a range of -0.20% to +0.20%.
