2. Press the key to see MEDIA REG menu options.
Selecting a media type number (SELECT MEDIA)
Select the media type number you intend to modify or create. You can choose from 01 to 20.
Parameters: media type number (01 to 20).
NOTE All changes to settings in the MEDIA REG menu will apply to the media that you select
or create in the SELECT MEDIA option.
Setting a media type name (RENAME MEDIA)
Rename a media type you want to modify or create.
Name the media type using up to six characters.
Parameters: a six-digit name.
Media advance value (MEDIA ADV VALUE)
Use this option to set the media advance value for the selected media type. This value is obtained from the
Media Advance print. See How do I…
Calibrate media advance for the step by step procedure.
NOTE This value will only be applied by the printer front panel setting if the ADVANCE PREF
option is set to FRONT PANEL.
Parameters: XXX.XX% (97.00 to 103.00%)
ENWW The MEDIA REG menu 171
Tell me about… (menus)
