Select the number you want to change by using the and keys and change the numeric value using

the

and keys.

Printhead nozzle position adjustment

Use the printhead nozzle position test patterns to calibrate the printhead nozzle positions.

To print the printhead nozzle position pattern:

1. In the TEST PRINTS menu scroll to the NOZZLE POS ADJ option and press the OK key.

2. Press the OK key to start printing.

1. Use section 1 to identify the printhead nozzle to be used as the reference.

2. Use section 2 to determine the correction value for the other printheads.

3. Identify the line of the printhead nozzle closest to the print platen (indicated as A in the image). In this

example, the printhead nozzle (that is closest to the print Platen) to be used as the reference is

indicated as B in the image.

124 Chapter 7 How do I get the best image quality ENWW
