Specifications
Item Specification / Function
Print technology Piezo—electric inkjet printheads
Resolution — High quality 720 dpi × 720 dpi
Resolution — Standard 720 x 720 dpi
Resolution — Fine draft 540 x 720 dpi
Resolution — Draft 720 x 360 dpi
Print speed About four minutes / A0 with 4 pass printing (changes according to surrounding
temperature and printhead temperature)
Media feed/delivery direction Rear media supply, front media delivery
Media type PVC, banner, Vinyl chloride, Tarpaulin
Media width Maximum 64 inch
Ink cartridge Six colors (black, cyan, magenta, yellow, light magenta, light cyan) 500 ml capacity
Noise Standby: 45 dB(A) or less, operating: 60 dB(A) or less (continuous sound)
Heat output 4860000J/H or less
Maximum print guaranteed range Area excluding top, bottom margins (5 mm) and right and left margins (5 mm); when using
the media edge guard, right and left margins will be 10 mm
Power supply voltage 100 to 240 VAC
Frequency 50/60 Hz ±1 Hz
Power consumption 1350 W or less (at operating)
External dimensions 2846 mm (W) x 830 mm (D) x 1255 mm (H) ±10 mm
Weight 210 kg or less (excluding media roll and ink)
Operating temperature/humidity
range
15 to 30 °C / 30% to 70% RH (no condensing)
Non-operating temperature/humidity
range
5 to 35 °C / 10% to 80% RH or less (no condensing)
Installation space 3650 mm (W) x 2830 mm (D) x 1800 mm (H)
Maintenance space 3650 mm (W) x 2830 mm (D) x 1800 mm (H)
