Changing Digital R2 MFC - Mexico Parameters
The E1 circuit card must first be assigned to the Digital R2 MFC - Mexico
protocol to use this procedure. See Assigning the Digital R2 MFC - Mexico
Protocol to E1 Circuit Cards on page 164 for more information about making
the initial assignment.
Note: Before attempting to make any assignment changes to circuit
cards, they must be in the “manoos” state. See Equipment State
on page 103 in Chapter 3, Voice System Administration , for
additional information.
If you change digital protocol assignments on the voice system,
you must also make the change on the switch.
To change the Digital R2 MFC - Mexico parameters:
1 Start at the Digital R2 MFC Protocol - Mexico menu (Figure 93 on page
164) and select:
The system displays the Change Parameters: Digital R2 MFC Protocol -
Mexico window (Figure 95 on page 169
).
> Change Parameters
