Parameters
port-no
Port number. (1 ~ 26)
Examples
N-TRON/Admin#[1]> port get duplexmode 4
Duplex mode of [4] port is: [half]
N-TRON/Admin#[2]> port get duplexmode 23
Duplex mode of [23] port is: [full]
NOTES Check whether port-no is in the valid range. (1 ~ 26)
Set the port duplex mode
Command Name
port set duplexmode
Description Sets the port duplex mode (HALF_DUPLEX / FULL_DUPLEX) for a
given port number.
Syntax port set duplexmode <port-no> <full | half>
Parameters
port-no
Port number. (1~24)
full | half
Duplex mode of the port. Duplex mode must be either
FULL_DUPLEX or HALF_DUPLEX.
Examples
N-TRON/Admin#[1]> port set duplexmode 4 full
N-TRON/Admin#[2]> port set duplexmode 4 half
NOTES Check whether port-no is in the valid range. (1 ~ 24)
Set the Lockstate of a given port
Command Name
port set lockstate
Description Sets the lock state of a given port to either enable or disable. If the port lock
is enabled, the switch can process the data packets only from locked MAC
addresses. Other data packets will not be processed.
Syntax port set lockstate <port-no> <enable | disable>
Parameters
port-no
port number (1 ~ 26)
enable | disable
Lock enable or disable
Examples
N-TRON/Admin#[1]> port set lockstate 5 disable
N-TRON/Admin#[2]> port set lockstate 8 enable
NOTES Once the port is locked, all the MACs that are learned on that port are
treated as static MACs. This means the switch can process the packets
from those MACs only. It will discard all packets from other MACs.
Because the MAC is set for that port, it will only be addressable via that
port.
Get Lock State
Command Name
port get lockstate
Description Gets the lock state for a given port.
Syntax port get lockstate <port-no>
Parameters
port-no
port number (1 ~ 26).
Examples
N-TRON/Admin#[1]> port get lockstate 6
LockState : [enable]
N-TRON/Admin#[2]> port get lockstate 24
LockState : [disable]
NOTES Check whether port-no is in the valid range. (1 ~ 26)
Get Auto-negotiation State
Command Name
port get autonego
Description Gets the auto negotiation mode for a given port.
Syntax port get autonego<port-no>
Parameters
port-no
Port number (1 ~ 24).
Examples
N-TRON/Admin#[1]> port get autonego 6
Auto negotiation mode is : [enabled]
N-TRON/Admin#[2]> port get autonego 24
