WR3000 4-Port Wireless DSL/Cable Router
®
22
3.4.1 Wizard Setup - Ethernet - Continued
Type the username given to you by your ISP.
Type the username given to you by your ISP.
Type the password associated with the username above.
The WR3000 Wireless Router will fi nd the Roadrunner Server IP if this fi eld is left
The WR3000 Wireless Router will fi nd the Roadrunner Server IP if this fi eld is left
blank. If it does not, then you must enter the authentication server IP address.
Type the domain name of the Telia login server, for example “logini .telia.com”.
Type the domain name of the Telia login server, for example “logini .telia.com”.
This fi eld is not available on all models.
The Telia server logs the WR3000 Wireless Router out if the WR3000 Wireless
The Telia server logs the WR3000 Wireless Router out if the WR3000 Wireless
Router does not log in periodically. Type the number of minutes from 1 to 59 (30
recommended) for the WR3000 Wireless Router to wait between logins.
This fi eld is not available on all models.
to proceed to the next page.
Click Back to go back to the previous page.
Click Back to go back to the previous page.
Point-to-Point Tunneling Protocol (PPTP) is a network protocol that enables transfers of data
from a remote client to a private server, creating a Virtual Private Network (VPN) using
PPTP supports on-demand, multi-protocol, and virtual private networking over public networks,
Refer to the appendix for more information on PPTP.
WIZARD
Back Next
PPTP
ISP Parameters for Internet Access
Encapsulation
User Name
Password
Nailed-Up Connection
Idle Timeout
100 (In Seconds)
PPTP Configuration
My IP Address
10.0.0.140
My IP Subnet Mask
Server IP Address
Connection ID/Name
0.0.0.0
10.0.0.138
The WR3000 Wireless Router
supports one PPTP server
connection at any given time.
