WR3000 4-Port Wireless DSL/Cable Router
®
50
7.3 Confi guring WEP Encryption
In order to confi gure and enable WEP encryption; click
display the Wireless screen.
The following table describes the wireless LAN security labels in this screen.
to allow wireless stations to communicate with the Wireless Routers
without any data encryption. Select
This fi eld is activated when you select
This fi eld is activated when you select
from the drop-down list box.
Select this option in order to enter ASCII characters as the WEP keys.
Select this option in order to enter ASCII characters as the WEP keys.
Select this option in order to enter hexadecimal characters as the WEP keys.
Select this option in order to enter hexadecimal characters as the WEP keys.
The WEP keys are used to encrypt data. Both the WR3000 Wireless Router and the
wireless stations must use the same WEP key for data transmission.
then enter any 5 ASCII characters or 10 hexadecimal characters
(“0-9”, “A-F”). If you chose
then enter 13 ASCII characters or 26 hexadecimal
characters (“0-9”, “A-F”).
You must confi gure all four keys, but only one key can be activated at any one time. The
Continued on the next page.
Local User
Database
MAC Filter
Roaming
802.1x
Apply Reset
WIRELESS LAN
Wireless
RADIUS
Enable Wireless LAN
Enable Intra-BSS Traffic
Enable Breathing LED
ESSID
Wireless
Hide ESSID
Choose Channel ID
RTS/CTS/Threshold
Scan
Channel-06 2412 MHz or
0
2432
(0-2432)
(256-2432)
WEP Encryption
Fragmentation Threshold
64-bit WEP
Authentication Method
ASCII Hex
Key 1
Key 2
Key 3
Key 4
Number of Wireless Stations Allowed
32
(1-99)
Output Power
12345
12345
12345
12345
64-bit WEP: Enter 5 ASCII characters or 10 hexadecimal characters (”0-9”, “A-F”) for each Key (1-4).
128-bit WEP: Enter 13 ASCII characters or 26 hexadecimal characters (”0-9”, A-F”) for each Key (1-4).
(Select one WEP key as an active key to encrypt wireless data transmission.)
17dBm(50mW)
Auto
