Chapter 3 Configuring Switch Alarms
Monitoring and Maintaining Switch Alarms Status
Attaching an Alarm Profile to a Specific Port
Enabling SNMP Traps
Monitoring and Maintaining Switch Alarms Status
relay-major {fcs-error | link-fault |
not-forwarding | not-operating}
(Optional) Configures the alarm to send an alarm
trap to the relay.
syslog {fcs-error | link-fault | not-forwarding |
not-operating}
(Optional) Configures the alarm to send an alarm
trap to a syslog server.
Command Purpose
Step 1
configure terminal Enters global configuration mode.
Step 2
interface port interface Enters interface configuration mode.
Step 3
alarm-profile name Attaches the specified profile to the interface.
Step 4
end Returns to privileged EXEC mode.
Step 5
show alarm profile Verifies the configuration.
Step 6
copy running-config startup-config (Optional) Saves your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enters global configuration mode.
Step 2
snmp-server enable traps alarms Enables the switch to send SNMP traps.
Step 3
end Returns to privileged EXEC mode.
Step 4
show alarm settings Verifies the configuration.
Step 5
copy running-config startup-config (Optional) Saves your entries in the configuration file.
Table 3-4 Commands for Displaying Global and Port Alarm Status
Command Purpose
show alarm description ports Displays an alarm number and its text description.
show alarm profile [name] Displays all alarm profiles in the system or a specified profile.
show alarm settings Displays all global alarm settings on the switch.
show env {alarm-contact | all | power |
temperature}
Displays the status of environmental facilities on the switch.
show facility-alarm status [critical | info |
major | minor]
Displays generated alarms on the switch.
Command Purpose
