Monitoring Alarms from the Live View
Endura Mapping gives operators the ability to display the physical location of cameras, alarms, and other
Endura devices throughout a facility. This spacial representation of the facility eliminates the need to
memorize the location of a camera that is identified only by a number or name. While monitoring a map in
Endura Mapping, operators can perform several tasks with the use of animated icons and innovative
dialog boxes.
• View a list of alarms associated with an icon (refer to page 17).
• Acknowledge alarms, set alarms to snooze, and comment on alarms (refer to page 18).
• View live video from cameras associated with the icon (refer to page 19).
• View recorded video associated with an alarm (refer to page 19).
• Send video to an external monitor on the Endura System (refer to page 20).
• Send video to a workspace in your own software (refer to page 20).
• Activate a relay (refer to page 21).
For detailed instructions on monitoring alarms, refer to the operation manual or the online Help. To monitor
alarms and review video, you must view maps from the Live Mode screen.
Figure 12. Endura Mapping Live View Screen
