Monitoring and Analyzing Switch Operation
Status and Counters Data
ProCurve(config)# show system fans
Fan Information
Num | State | Failures
-------+-------------+----------
Sys-1 | Fan OK | 0
0 / 1 Fans in Failure State
0 / 1 Fans have been in Failure State
Figure B-4. Example of System Fan Status
ProCurve(config)# show system
Status and Counters - General System Information
System Name : ProCurve Switch
System Contact :
System Location :
MAC Age Time (sec) : 300
Time Zone : 0
Daylight Time Rule : None
Software revision : T.13.XX Base MAC Addr : 001635-b57cc0
ROM Version : K.12.12 Serial Number : LP621KI005
Up Time : 51 secs Memory - Total : 152,455,616
CPU Util (%) : 3 Free : 110,527,264
IP Mgmt - Pkts Rx : 0 Packet - Total : 6750
Pkts Tx : 0 Buffers Free : 5086
Lowest : 5086
Missed : 0
Figure B-5. Example of Switch System Information
Task Monitor—Collecting Processor Data
The task monitor feature allows you to enable or disable the collection of
processor utilization data. The task-monitor cpu command is equivalent to the
existing debug mode command “taskusage -d”. (The taskUsageShow command
is available as well.)
When the task-monitor command is enabled, the show cpu command summa-
rizes the processor usage by protocol and system functions.
B-9
