Monitoring and Analyzing Switch Operation
Traffic Mirroring
ProCurve_8200(config)# show monitor 3
Network Monitoring
Session: 3 Session Name:
Policy: no policy relationship exists
Mirror Destination: A1 (Port)
Monitoring Sources Direction
------------------ --------
-
MAC: 112233-445566 Source
The MAC address used to select packets in a
local mirroring session is displayed in these
columns.
Figure B-38. Displaying a MAC-based Mirroring Session
Displaying a Local Mirroring Session. When used to display the configu-
ration of a local session, the show monitor command displays a subset of the
information displayed for a remote mirroring session. For example, Figure B-
39 displays a local mirroring configuration for a session configured as follows:
■ Session number: 1
■ Session name: Detail
■ Classifier-based mirroring policy, “MirrorAdminTraffic”, is used to select
inbound traffic on port B1.
■ Mirrored traffic is sent to exit port B3.
ProCurve_8200(config)# show monitor 1
Network Monitoring
Session: 1 Session Name: Detail
Policy: MirrorAdminTraffic
Mirror Destination: B3 (Port)
Monitoring Sources Direction
------------------ --------
-
Port: B1 In
Figure B-39. Displaying the Configuration of a Local Mirroring Session
B-81
