EN General troubleshooting flowchart 117
General Troubleshooting Flowchart (continued)
Refer to the section Image Formation Troubleshooting, later in this
chapter.
If the engine test produces a clear print image, yet a Self-Test is not
generated by initiating the Control Panel self-test procedure, replace the
Formatter PCA.
EXIT
Perform an
Engine Test
Is the
Engine Test
image being
printed
clearly?
Perform a Control
Panel Self-Test
Is the
Self-Test
image being
printed
clearly?
No
No
Ye s
Ye s
