EN Parts diagrams 149
Table 8-3 Covers and doors
Ref LaserJet 5L
part number
LaserJet 6L
part number
LaserJet 6L Pro
part number
Qty Description
1 RB1-7211-000CN RB2-1637-000CN RB2-6213-000CN 1 Input Extender 1/Tray, Sub
2 RB1-7212-000CN RB2-1638-000CN n/a 1 Input Extender 2
3 RB1-7333-000CN RB2-1636-000CN RB2-1636-000CN 1 Back Cover
4 RG5-1995-000CN RG5-3443-000CN n/a 1 Main Cover
4A RB1-7278-000CN RB2-1644-000CN RB2-1644-000CN 1 Face-up/Face-down Switch
5 RB1-7326-000CN RB2-1696-000CN RB2-1696-000CN 1 Output Extender 1
6 RB1-7327-000CN RB2-1696-000CN RG5-1697-000CN 1 EP Door Chimney
7 RB1-7331-000CN RB2-1696-000CN n/a 1 Output Extender 2
8 RF5-1501-030CN RF5-2352-000CN RG5-5475-000CN 1 EP Door Assembly/Cover
Assembly
8B RB1-7335-000CN RB2-1641-000CN RB2-6229-000CN 1 Nameplate
9 RG5-1944-000CN RG5-3488-000CN RG5-3488-000CN 1 Input Assembly 1
10 RG5-1945-000CN RG5-3491-000CN RG5-3491-000CN 1 Input Assembly 2
11 XA9-0724-000CN XA9-0724-000CN XA9-0724-000CN 2 Screw RS, M3x8
13 RB1-7321-000CN RB2-1639-000CN n/a 1 Memory Door
14 n/a n/a RG5-5475-000CN Cover Assembly
501 XB4-7401-007CN XB4-7401-007CN XA9-1262-007CN 2 Screw, TP, PH, M4x10
502 XB6-7300-807CN XA9-0267-000CN XA9-0267-000CN 2 Screw, Top, M3x8
