EN Alphabetical parts list 169
Fuse 101 (220 V) VD7-0643-151CN 8-6
Fuse 102 (110 V) RH3-8003-000CN 8-6
Fuser Cable Guide RB1-7130-000CN 8-4 6
Fuser Connector VS1-5057-002CN 8-5 15
Fuser Exit Roller Assembly (5L) RF5-1522-000CN 8-9 7
Fuser Exit Roller Assembly (6L and 6L Pro) RF5-2368-000CN 8-9 7
Fuser Paper Guide RB1-7247-000CN 8-4 2
Fuser Pressure Plate RF5-1517-000CN 8-5 5
Fuser Release Kit RY7-5007-000CN 8-3 6
Fuser Release Tab RB1-7105-000CN 8-3 3
Fuser Roller Bushing (5L) RB1-7289-000CN 8-9 4
Fuser Roller Bushing (6L and 6L Pro) RB2-1690-000CN 8-9 4
Gear Kit #1 RY7-5005-000CN 8-3 1
Gear Kit #2 (5L) RY7-5006-000CN 8-3 8
Gear Kit #2 (6L and 6L Pro) RY7-5036-000CN 8-3 8
Gear Plate (5L) RB1-7106-000CN 8-3 4
Gear Plate (6L and 6L Pro) RB2-1632-000CN 8-3 4
Ground Clip, Scanner (5L and 6L) RB1-7385-000CN 8-3 20
Ground Clip, Scanner (6L Pro) HB1-3418-000CN 8-3 20
Grounding Spring (6L Pro) RB1-7172-000CN 8-7 19
Guide Sheet RB2-6226-000CN 8-4 1
Heating Element (110 V) (5L) RG5-1964-000CN 8-5 16
Heating Element (110 V) (6L) RG5-3459-000CN 8-5 16
Heating Element (220 V) (5L) RG5-1965-000CN 8-5 16
Heating Element (220 V) (6L) RG5-3463-000CN 8-5 16
Heating Element (220 V) (6L Pro) RG5-5517-010CN 8-5 16
I/O Sheet Metal RB1-7305-000CN 8-4 12
Idler Roller (5L) RB1-7226-000CN 8-8 9
Idler Roller (6L and 6L Pro) RB2-1699-000CN 8-8 9
Idler Roller Shaft Assembly RG5-1947-000CN 8-7 9
Input Assembly 1 (5L) RG5-1944-000CN 8-2 9
Input Assembly 1 (6L and 6L Pro) RG5-3488-000CN 8-2 9
Input Assembly 2 (5L) RG5-1945-000CN 8-2 10
Input Assembly 2 (6L and 6L Pro) RG5-3491-000CN 8-2 10
Input Extender 1 (5L) RB1-7211-000CN 8-2 1
Input Extender 1 (6L) RB2-1637-000CN 8-2 1
Input Extender 1 (6L Pro) RB2-6213-000CN 8-2 1
Input Extender 2 (5L) RB1-7212-000CN 8-2 2
Input Extender 2 (6L and 6L Pro) RB2-1638-000CN 8-2 2
Input Sensor Assembly RY7-5009-000CN 8-7 3
JP Protector RB1-7334-000CN 8-10 8
Kick Plate Spring RS5-2501-000CN 8-7 14
Table A-1 Alphabetical parts list (Continued)
Description Part No. Fig. Ref.
