Printer Specifications
Specifications and Regulatory Information C-5
Specifications
Figure C-2 D640 Printer required service area dimensions
Table C-4 Printer electrical specifications
Note If the printer is connected to a line conditioner, make sure the line conditioner can
support the in-rush current requirement for the printer.
Item Specifications
Input power
Voltage 120 to 127 VAC
±
10%, 12A
200 to 240 VAC
±
10% 7A
Phase Single-phase
Frequency 50/60Hz
±
5%
Power consumption
1,300 VA or less than during operating
Heat production
894 kcal per hour (3550 Btu per hour)
In-rush current
Up to 100 amps
Printer
Operating
Side
23.0 in.
(585 mm)
33.5 in.
(850 mm)
33.5 in.
(850 mm)
25.6 in.
(650 mm)
33.5 in.
(850 mm)
25.2 in.
(640 mm)
84.3 in.
(2140 mm)
90.0 in.
(2285 mm)
