Clearing Paper Path Jams
Printer Tasks 3-35
Printer Tasks
6. Push the HCI towards the printer until it latches and check the Control Panel.
7. Press Clear. If there is no paper jam indication, you are ready to resume printing. If the
Control Panel still shows a jam, search the area again, or the area indicated on the
Control Panel.
Clearing Paper Path Jams
Once the paper has cleared the feed mechanisms, which carry the paper up to the drum unit,
there are places where jams can occur between the drum unit and the area just before the
ejection unit. These areas are: at the fuser, in the duplex path, and the print unit path around the
reversing unit. This is indicated on the Control Panel by the blinking paper path shown in
Figure 3-49.
Figure 3-49 Paper path jams indication
Clear
Offline
Menu Test PapSize
LTR
LTR
LTR
*Offline*
Blinking
Fuser unit jam
Duplex path jam
Print unit path jam
*****:
PCL
Remove paper & Press Clear
600 dpi
