15
Fixed-Type Camera
Fixed-Type Camera
• 1/3-type Super HAD CCD
• Horizontal resolution - 330 TV lines
• High sensitivity - 0.6 lx (F1.2, 50IRE)
• Built-in tripod screw holes for easy installation
• Digital Signal Processing (DSP) technology provides powerful picture-contrast
control
• Sync system: AC line lock
• Backlight Compensation: ON/OFF switchable
• AGC: TURBO/OFF switchable
• Wide range of CCD shutter speed (ON/OFF switchable, 1/50 to 1/100,000 s)
• CCD IRIS function allows for the use of low cost manual iris lenses
• Wide range Auto Tracing White balance (ATW)
• Accepts video or DC auto iris lenses
• CS-mount
SSC-DC198P
SSC-DC198P Rear Panel
• 1/3-type CCD with Super HAD technology
• Horizontal resolution - 330 TV lines
• High sensitivity - 0.6 lx (F1.2, 50IRE)
• Digital Signal Processing (DSP) technology provides powerful picture-contrast
control
• CCD IRIS function allows for the use of low cost manual iris lenses
• Built-in tripod screw holes for easy installation
• Backlight compensation: ON/OFF switchable
• AGC: TURBO/OFF switchable
• Wide range of CCD shutter speed (ON/OFF switchable, 1/60 to 1/100,000 s
(SSC-DC174), 1/50 to 1/100,000 s (SSC-DC172P))
• Wide range Auto Tracing White balance (ATW)
• Accepts DC auto iris lenses
• CS-mount
• Variety of power options
SSC-DC174: AC 24 V operation
SSC-DC172P: DC 12 V operation
SSC-DC174/SSC-DC172P
SSC-DC174 Rear Panel SSC-DC172P Rear Panel
