SPECIFICATIONS
SNC-RZ30N/2 SNC-RZ30P/2
Camera
Image device 1/6-type Super HAD CCD
Number of effective pixels 630,000 (962 x 654) 740,000 (962 x 774)
(H x V)
Electronic shutter Auto/Manual
Gain control Auto/Manual
Exposure control Auto/Shutter-priority/Iris-priority/Manual/Backlight compensation
White balance mode Auto/Indoor/Outdoor/One push auto/ATW/Manual
Lens type Auto-focus zoom lens
Zoom ratio 25x Optical (12x Digital)
Horizontal viewing angle 45 to 2.0 degrees
Focal length f=2.4 to 60 mm
F number F1.6 (Wide),F2.7 (Tele)
Pan angle -170 to +170 degrees
Tilt angle -90 to +25 degrees
Other functions Day/Night,Image Flip,Activity Detection,Image stabilizer
Image size 36 x 480,640 x 480, 320 x 240,160 x 120 736 x 544,640 x 480, 320 x 240,160 x 120
Compression format JPEG
Maximum frame rate 30 fps (640 x 480) 25 fps (640 x 480)
Network
Protocols TCP/IP, ARP, ICMP, DHCP,DNS,HTTP, FTP,SMTP, NTP, SNMP(MIB2)
Number of clients 50
Interface
Ethernet 100Base-TX/10Base-T (RJ-45)
Serial interface RS-485/RS-232C
Card slot PC card Type II x 2
Analog video output BNC x 1,1.0 Vp-p, 75 Ω unbalanced,sync negative
I/O port Sensor in x 3,Alarm out x 2
Analog video output
Signal system NTSC PAL
Horizontal resolution 480 TV lines
S/N ratio more than 48 dB
Minimum illumination Color:2.5 lx (AGC ON,F1.6,50IRE), B/W:0.1 lx (AGC ON,F1.6, 50IRE)
General
Mass approx.1,200 g (2 lb 10 oz)
Dimensions (W x H x D) 140 x 175 x 144 mm (5
5
/
8 x 7 x 5
3
/
4 inches) without projection
Power requirements DC 12 V
Power consumption 21.6 W max.
Operating temperature 0 to 40°C (32 to 104°F)
Storage temperature -20 to 60°C (-4 to 140°F)
Supplied accessories
AC power adaptor,AC power cord,Ceiling bracket (A),Ceiling bracket (B),Wire rope,Fixing screws (+PSW 3x6), Shoulder screw M4, I/O receptacle,
Rubber foot,Clamp filter, CD-ROM (User's guide, setup program),Installation manual
System requirements
Operating system Windows 98/98SE/Me/NT4.0/2000/XP
Processor CPU:Pentium III 500 MHz or higher (Pentium 4, 1GHz or higher recommended)
Memory RAM:128 MB or more
Web browser Microsoft Internet Explorer® Ver.5.5 or 6.0
