SNC-RZ25N SNC-RZ25P SNC-P5
Camera
Image device 1/4-type CCD with EXwave HAD Technology 1/4 type progressive scan CCD
Number of effective pixels 380,000 (768 x 494) 440,000 (752 x 582) 330,000 (659 x 494)
(H x V)
Electronic shutter Auto/Manual
Gain control Auto/Manual
Exposure control Auto/Shutter-priority/Iris-priority/Manual/Backlight compensation Auto/Shutter priority/ Manual
White balance mode Auto/Indoor/Outdoor/One push auto/ATW/Manual ATW/Indoor/Outdoor/One push auto/Manual
Lens type Auto-focus zoom lens Pan focus zoom lens
Zoom ratio 18x Optical (12x Digital) 3x optical
Horizontal viewing angle 48 to 2.7 degrees 55.8 to 20 degrees
Focal length f=4.1 to 73.8 mm F2.8 (Wide),F3.9 (Tele)
F number F1.4 (Wide),F3.0 (Tele) f3.4 to 10.2 mm
Pan angle -170 to +170 degrees -60 to +60 degrees
Tilt angle -90 to +30 degrees -65 to +10 degrees
Other functions Day/Night ,Image Flip,Motion Detection Motion Detection
Image size
JPEG 640 x 480,480 x 360, 384 x 288,320 x 240, 256 x 192,160 x 120
MPEG-4 640 x 480,480 x 360, 384 x 288,320 x 240,256 x 192, 160 x 120
Compression format JPEG/MPEG-4 (Selectable)
Maximum frame rate
JPEG 30 fps (320 x 240) 25 fps (320 x 240) 30 fps (320 x 240)
MPEG-4 30 fps (320 x 240) 25 fps (320 x 240) 30 fps (320 x 240)
Audio
Compression format G.726 (40, 32,24,16 kbps),G.711 (64 kbps) G.711(64KBps)/G.726 (40,32,24,16KBps)
Built-in microphone Electret condenser microphone (omni-directional)
Network
Protocols TCP/IP, UDP,ARP,ICMP, DHCP,DNS, HTTP, FTP,SMTP, NTP,SNMP(MIB2), RTP/RTCP, PPPoE
Number of clients JPEG:20, MPEG-4:10
Interface
Ethernet 100Base-TX/10Base-T (RJ-45)
Serial interface RS-232C –
Card slot Compact Flash type x 1
Analog video output BNC x 1,1.0 Vp-p, 75 Ω unbalanced,sync negative Mini Jack,1.0 Vp-p,75 Ω,Sync negative
I/O port Sensor input x 2,Alarm output x 2 Sensor input x 2,Alarm output x 1
External microphone input Mini-jack (monaural),4.7 kΩ, 2.5 V plug-in power Mini-jack(monaural),2.2 kΩ, 2.5V plug-in power
Audio line output Mini-jack (monaural), max output level:1Vrms
Analog video output
Signal system NTSC PAL NTSC/PAL
Horizontal resolution 480 TV lines 400 TV lines
S/N ratio more than 50 dB more than 48 dB
Minimum illumination Color:0.7 lx (AGC ON,F1.4,50IRE) 3.5 lx (AGC ON, F2.8,30IRE)
B/W:0.06 lx (AGC ON,F1.4, 50IRE)
General
Mass approx.1,300 g (2 lb 14 oz) Camera:approx.380 g (13 oz),
Stand:approx. 360 g (13 oz)
Dimensions (W x H x D) 140 x 200 x 148 mm ( 5
5
/8 x 7
7
/8 x 5
7
/8 inches) without projections Camera:130 x 130 x 110 mm
(5
1
/8x 5
1
/8x 4
3
/8inches) without projections
Stand:130 x 178 x 142 mm
(5
1
/8 x 7
1
/8 x 5
5
/8 inches)
Power requirements AC 24 V (50/60Hz),DC 12 V DC12 V
Power consumption 18 W max 6.2 W max
Operating temperature 0 to 40°C (32 to 104°F) 0 to +35°C (32 to 95°F)
Storage temperature -20 to 60°C (-4 to 140°F) -20 to +60°C (-4 to +140°F)
Supplied accessories
Ceiling Bracket (A), Ceiling Bracket (B),Wire rope,Tapping screw (M3x6), AC power adaptor,AC Power cord, Stand,
CD-ROM (User's guide, supplied programs),Installation manual Wall-mount bracket,Rubber feet,
Drop-prevention strap,Tapping screws, CD-ROM
(user’s guide,supplied programs),Installation manual
System requirements
Operating system Windows 2000/XP
Processor CPU:Pentium III 1 GHz or higher (Pentium IV,2 GHz or higher recommended)
Memory RAM:256 MB or more
Web browser Microsoft Internet Explorer
®
Ver.5.5 or 6.0
PTZ Cameras
