SPECIFICATIONS
SNC-CS3N SNC-CS3P SNC-P1
Camera
Image device 1/3-type CCD with Exwave HAD technology 1/4 type progressive scan CCD
Number of effective pixels 380,000 (768 x 494) 440,000 (752 x 582) 330,000 (659 x 494)
(H x V)
Electronic shutter Auto/Manual
Gain control Auto/Manual
Exposure control – Auto/Shutter priority/ Manual
White balance mode ATW ATW/Indoor/Outdoor/One push auto/Manual
Lens type Vari-focal auto iris lens Fixed focal lens
Zoom ratio 2.7x Optical –
Horizontal viewing angle 91 to 36 degrees 53.4 degrees
Focal length f=3.0 to 8.0 mm f=3.8 mm
F number F1.0 (Wide),F1.4 (Tele) F2.0
Other functions Activity Detection Motion Detection
Image size
JPEG 736 x 480,640 x 480, 320 x 240,160 x 120 736 x 544,640 x 480, 320 x 240,160 x 120 640 x 480,320 x 240, 160 x 120
MPEG-4 – 640 x 480,320 x 240, 160 x 120
Compression format JPEG MPEG-4, JPEG
Maximum frame rate
JPEG 30 fps (640 x 480) 25 fps (640 x 480) 30 fps (320 x 240)
MPEG-4 – 30 fps (320 x 240)
Audio
Compression format – G.711(64KBps)/G.726 (40,32,24,16KBps)
Built-in microphone – Electret condenser microphone (omni-directional)
Network
Protocols TCP/IP,ARP,ICMP, DHCP, NTP, DNS,HTTP,FTP,SMTP, SNMP (MIB2) TCP/IP,UDP,ARP,ICMP,DHCP, DNS, HTTP, FTP,SMTP,
NTP,SNMP(MIB2), RTP/RTCP,PPPoE
Number of clients 50 JPEG: 20, MPEG-4:10
Interface
Ethernet 100Base-TX/10Base-T (RJ-45)
Serial interface RS-232C –
Card slot PC card Type II x 1 –
Analog video output BNC x 1,1.0 Vp-p, 75 Ω,unbalanced, sync negative, Mini Jack,1.0 Vp-p,75 Ω, Sync negative Mini Jack,1.0 Vp-p,75 Ω,Sync negative
I/O port Sensor in x 1,Alarm out x 2 Sensor input x 1,Alarm output x 1
External microphone input – Mini-jack (monaural),2.2 kΩ,2.5 V plug-in power
Audio line output – Mini-jack (monaural), max output level:1 Vrms
Analog video output
Signal system NTSC PAL NTSC/PAL
Horizontal resolution 480 TV lines 400 TV lines
S/N ratio more than 50 dB (AGC OFF,Weight ON) more than 48 dB
Minimum illumination 0.5 lx (AGC ON,F1.0,50IRE) 1.2 lx (AGC ON, F2.0,30IRE)
General
Mass approx.650 g ( 1 lb 7 oz) Camera:approx.225 g (8 oz),
Stand:approx. 180 g (6 oz)
Dimensions (W x H x D) 70 x 57 x 199 mm (2
7
/8 x 2
1
/4 x 7
7
/8 inches) Camera:100 x 36 x 139 mm
(4 x 1
7
/16 x 5
1
/2 inches) without projection
Stand:120 x 142 x 150mm (4
3
/4 x 5
5
/8 x 6 inches)
Power requirements AC 24 V (50/60Hz),DC 12 V DC12 V
Power consumption 8 W 3.5 W
Operating temperature -10 to 50°C (14 to 122°F) 0 to +35°C (32 to 95°F)
Storage temperature -20 to 60°C (-4 to 140°F) -20 to +60°C (-4 to +140°F)
Supplied accessories
CD-ROM (setup program,user's guide),Wire rope,Shoulder screw M4, Installation manual AC power adaptor,AC power cord, Stand,
Wall-mount bracket, Rubber foot,
Drop-prevention strap,Tapping screws,
CD-ROM (user’s guide,supplied programs),
Installation manual
System requirements
Operating system Microsoft Windows 98/98SE/ME/NT4.0/2000XP Windows 2000/XP
Processor CPU:Pentium III,500 MHz or higher (Intel Pentium 4, 1 GHz or higher recommended) CPU:Pentium III 1 GHz or higher
(Pentium IV,2GHz or higher recommended)
Memory RAM:128 MB or more RAM :256 MB or more
Web browser Microsoft Internet Explorer version 5.5 or 6.0
