SPECIFICATIONS
SSC-M383 SSC-M383CE SSC-M388CE SSC-M183 SSC-M183CE SSC-M188CE
Camera
Image device 1/3-type CCD with Exwave HAD technology
Number of effective pixels 370,000 (768 x 494) 430,000 (752 x 582) 250,000 (510 x 492) 291,000 (500 x 582)
(H x V)
Auto Gain Control TURBO/OFF switchable
White balance mode ATW
Lens type CS-mount,DC/Video servo auto iris
CCD iris ON/OFF switchable, ON/OFF switchable, 1/50 to 1/100,000 s ON/OFF switchable, ON/OFF switchable, 1/50 to 1/100,000 s
1/60 to 1/100,000 s 1/60 to 1/100,000 s
Back-Light Compensation ON/OFF switchable
Analog video output BNC x 1,1.0 Vp-p, 75 Ω,Sync negative
Signal system EIA CCIR EIA CCIR
Sync system Internal/AC Line lock AC Line lock Internal/AC Line lock AC Line lock
Horizontal Resolution 570 TV lines 380 TV lines
S/N ratio More than 50 dB (AGC OFF,WEIGHT ON)
Minimum illumination 0.07 lx (50IRE,F1.2,Turbo AGC ON) 0.06 lx (50IRE, F1.2,Turbo AGC ON)
General
Mass approx.360 g (13 oz) approx. 390 g (14 oz) approx.360 g (13 oz) approx. 390 g (14 oz)
Dimensions (W x H x D) 60 x 54 x 120 mm (2
3
/8 x 2
1
/4 x 4
3
/4 inches)
Power requirements AC 24 V ±10%,60 Hz AC 24 V ±10%, 50 Hz AC 220 to 240 V ±10 %, AC 24 V ±10%, 60 Hz AC 24 V ±10%,50 Hz AC 220 to 240 V ±10 %,
or DC 12 V ±10% or DC 12 V ±10 % 50 Hz or DC 12 V ±10% or DC 12 V ±10% 50 Hz
Power consumption 2.6 W 2.5 W
Operating temperature -10 to 50°C (14 to 122°F)
Storage temperature -40 to 60°C (-40 to 140°F)
Supplied accessories
Lens mount cap, Operating instructions Lens mount cap, Lens mount cap, Operating instructions Lens mount cap,
Operating instructions, Operating instructions,
AC power cable AC power cable
SSC-CD73V SSC-CD73VP SSC-CD43V SSC-CD43VP
Camera
Image device 1/4-type Super HAD CCD
Number of effective pixels 370,000 (768 x 494) 430,000 (752 x 582) 430,000 (752 x 582)
(H x V)
Auto Gain Control TURBO/OFF switchable
White balance mode ATW
Lens type Vari-focal lens, CS-mount,DC servo auto iris
Focal length f=3.0 to 8.0 mm
Viewing angle W=84.6°(D), 66.6°(H),49.3°(V) W=84.7°(D),66.6°(H), 49.3°(V)
T=33.8°(D), 27°(H), 20.2°(V) T=33.6°(D), 26.9°(H), 20.1°(V)
CCD iris ON/OFF switchable, ON/OFF switchable, ON/OFF switchable, ON/OFF switchable,
1/60 to 1/100,000 s 1/50 to 1/100,000 s 1/60 to 1/100,000 s 1/50 to 1/100,000 s
Minimum object distance 0.2 m
Back-Light Compensation ON/OFF switchable
Analog video output BNC x 1,1.0 Vp-p, 75 Ω,Sync negative
Signal system NTSC PAL NTSC PAL
Sync system Internal/AC Line lock
Horizontal Resolution 480 TV lines 480 TV lines
S/N ratio More than 50 dB (AGC OFF,WEIGHT ON)
Minimum illumination Color:0.9 lx (50IRE, F1.0,AGC ON),B&W: 0.2 lx (50IRE,F1.0,AGC ON) Color:0.8 lx (50IRE, F1.0,AGC ON)
General
Mass approx.1,150 g (2 lb 10 oz) approx.440 g (16 oz)
Dimensions (W x H x D) 147 x 111 x 148 mm (5
7
/
8 x 4
3
/
8 x 5
7
/
8 inches) 121 x 107 x 123 mm (4
7
/
8 x 4
1
/
4 x 4
7
/
8 inches)
Power requirements AC 24 V ±10%,60 Hz or AC 24 V ±10%, 50 Hz or AC 24 V ±10%, 60 Hz or AC 24 V ±10%, 50 Hz or
DC 12 V ±10% 12 V ±10% DC 12 V ±10% 12 V ±10%
Power consumption 3.6 W 3.3 W
Operating temperature -20 to 50°C (-4 to 122°F)
Storage temperature -40 to 60°C (-40 to 140°F)
Supplied accessories
Screw TP4 x 30 (4), Monitor cable,Screwdriver, Screw TP4 x 30 (2), Dome cover screw, Monitor cable, Operating Instructions
External control terminal connector,Operating Instructions
ANALOG CAMERAS
Fixed-Type Cameras
Mini Dome Cameras
