YS-W270A YS-W270P YS-W170A YS-W170P
Video output BNC (x 8), composite video BNC (x 2),composite video
Signal system NTSC PAL NTSC PAL
Video input Camera in,BNC (x 4) Camera in, BNC (x 1)
External sync VS or VD-W
Internal sync MPX-VS or MPX-VD-W
Max.cable length 300 m (984 ft) using RG-59B/U
500 m (1640 ft) using RG-6A/U
600 m (1968 ft) using RG-11A/U
Cable compensation 3 positions
Power requirements AC 120 V, 60 Hz AC 220 to 240 V,50 Hz AC 120 V,60 Hz AC 220 to 240 V,50 Hz
Power consumption 92 W 49.5 W 27 W 15 W
Operating temperature -10 to 50°C (14 to 122°F)
Mass 3.8 kg (8 lb 6 oz) 1.9 kg (4 lb 3 oz)
Dimensions (W x H x D) 424 x 52 x 345 mm (16
3
/4 x 2
1
/8 x 13
5
/8 inches) 212 x 52 x 345 mm (8
8
/3 x 2
1
/8 x 13
5
/8 inches)
IMZ-RS300 Series
Intelligent Monitoring Software
Operating system* Windows 2000,Windows XP or Windows 2003 Server
Processor CPU:Pentium IV 2.4 GHz or higher
Memory RAM:512 MB or more
HDD 2 GB spare capacity
Video Card 1024 x 768,16/24-bit color
Network Interface Card (NIC) 100Base-T
Display Full-color display
Web Gateway
Operating system Windows 2000 or Windows XP
Java Runtime** Java Runtime Environment 1.4.2
Web Application Server** Apache Tomcat 5.0.18
Web Browser Internet Explorer Version 6.0 or later
Processor CPU:Pentium IV 2.4 GHz or higher
Memory RAM:512 MB or more
HDD 500 MB spare capacity
Video Card 1024 x 768,16/24-bit color
Network Interface Card (NIC) 100Base-T
Compression Server
Operating system Windows 2000 or Windows XP
Processor CPU:Pentium IV 2.4 GHz or higher
Memory RAM:512 MB or more
HDD 500 MB spare capacity
Video Card 1024 x 768,16/24-bit color
Network Interface Card (NIC) 100Base-T
Intelligent Monitoring Software Web Viewer
Operating system Windows 2000 or Windows XP
Java Runtime*** Java Runtime Environment 1.4.2
Web Browser Internet Explorer Version 6.0 or Later
Processor CPU:Celeron 2.0 GHz or higher
Memory RAM:512 MB or more
HDD 500 MB spare capacity
Video Card 1024 x 768,16/24-bit color
Network Interface Card (NIC) 100Base-T
* Please contact your local Sony office or authorized dealer for compatibility information on the Linux Operating System.
** Both Java Runtime Environment and Web Application Server are induded in the Web Gateway Module. *** Downloadable from Web Gateway.
CAMERA ADAPTORS
INTELLIGENT MONITORING SOFTWARE SYSTEM REQUIREMENTS
