SNC-CS50N SNC-CS50P
Camera
Image device 1/3-type SuperExwave CCD
Number of effective pixels 380,000 pixels 440,000 pixels
Electronic shutter 1/60 to 1/10,000 s 1/50 to 1/10,000 s
Gain control Auto/Manual (0 dB to +24 dB)
Exposure control Auto, Manual,EV compensation,Backlight compensation
White balance mode ATW/ATW pro/One-push auto
Lens type Vari-focal zoom lens
Zoom ratio –
Horizontal viewing angle 94 ° to 35 °
Focal length f=2.9 to 8.0 mm
F-number F0.95 to F1.6
Minimum object distance 300 mm
Other functions Day/Night,Intelligent Motion Detection,Intelligent Object Detection,
Anti-tampering,Image stabilizer
Image size (H x V) 640 x 480,320 x 240, 160 x 120
Compression format JPEG, MPEG-4,H.264
Maximum frame rate
JPEG/MPEG-4 30 fps (640 x 480) 25 fps (640 x 480)
H.264 10 fps (640 x 480) 8 fps (640 x 480)
Compression ratio approx.1/5 to 1/60 (10 steps)
Audio
Audio compression G.711/G.726 (40,32,24, 16 kbps)
Network
Protocols TCP/IP, HTTP,ARP, ICMP, FTP, SMTP, DHCP, DNS,NTP,SNMP (MIB-2),
and RTP/RTCP
Number of clients 20
Interface
Ethernet 10Base-T/100Base-TX (RJ-45)
Serial interface RS-232C (Transparency function)
PC card slot PC card x1 (Type II)
Analog video output BNC x1,1.0 Vp-p, 75 Ω
I/O ports Sensor in x2,Alarm out x2
External microphone input Mini-jack (monaural,2.2 kΩ 2.5 V plug-in power)
Audio line output Mini-jack (monaural), Max output level:1 Vrms
Analog video output
Signal system NTSC (Composite) PAL (Composite)
Horizontal resolution 540 TV lines
S/N ratio more than 50 dB
Min.illumination Color:0.4 lx (F 0.95, 50 IRE,AGC ON)
B/W:0.04 lx (F 0.95, 50 IRE,AGC ON)
General
Mass approx.750 g (1 lb 10 oz) excl. cover equipment,approx.880g (1 lb 15 oz) incl. cover equipment
Dimensions (W x H x D) 84 x 69 x 196 mm (3
3
/8 x 2
3
/4 x 7
3
/4 inches) excl.cover equipment, 84 x 69 x 265 mm (3
3
/8 x 2
3
/4 x 10
1
/2 inches) incl.cover equipment
Power requirements AC 24 V, DC 12 V,PoE
Power consumption 9 W max. (AC 24V)
Operating temperature 0 to 50 °C (32 °F to 122 ºF)
Storage temperature -40 to 60 °C (-40 °F to 140 ºF)
Supplied accessories
Wire rope, Shoulder screw M4,Cable cover,Front cover,Lens cable cover,Screw for front cover, CD-ROM (setup program, user's guide)
System requirements
Operating system Microsoft
®
Windows
®
2000/XP
Processor CPU: Intel
®
Pentium
®
III 1 GHz or higher
Memory RAM:256 MB or more
Web browser Microsoft Internet Explorer
®
Ver.6.0 or later
* The SNC-CS10 does not support for PPPoE.
28
SPECIFICATIONS
NETWORK CAMERAS
Fixed-Type Cameras
