10Ć29 Parts and DiagramsC4699Ć90000
Interface Cables
Parallel (Bi-Tronics/Centronics) Interface Cables
Computer
HP Part Number
Cable length Connector type at
DesignJet
330/350C
DesignJet
230/250C
compu
er en
o
ca
e
HP Vectra
with HP 24540A/B
serial/parallel interface card
using the parallel connector.
HP 9000 workstations, series
300, 400, 700.
IBM AT, IBM PS/2, IBM PC/XT
and compatible computers.
C2950A
C2951A
92284A 2.1 m (6.9 ft)
2.0 m (6.9 ft)
3.0 m (9.8 ft)
25-pin male
25-pin male
25-pin male
Serial (RS-232-C) Interface Cables
Computer
HP Part Number
Cable length Connector type at
DesignJet
330/350C
DesignJet
230/250C
compu
er en
o
ca
e
HP Vectra or HP 24541A/B
serial interface card (9-pin
connector).
HP 9000 workstations using
9-pin connectors.
IBM AT and compatible
computers using 9-pin serial
connectors.
24542G 24542G 3.0 m (9.8 ft) 9-pin female
HP Vectra PC with HP
24541A/B dual serial interface
card using the 25-pin connector.
HP Apollo workstation using an
SPE (Serial/Parallel Expansion)
option and supplied adapter
cable.
DEC VAX.
Sun workstation.
17255M 17255M 1.2 m (3.9 ft) 25-pin male
IBM PC, PC/XT, IBM PS/2 and
compatible computers
C2913A 17255D 1.2 m (3.9 ft) 25-pin female
DEC VAX using DEC BC22D,
BC03M, or equivalent
17355M 17355M 3.0 m (9.8 ft)
