PIM-SM (Sparse Mode)
Displaying PIM-SM Data and Configuration Settings
DownStream Interfaces:
– VLAN: Lists the VID of the destination VLAN on the next-
hop multicast router.
– Prune Reason: Identifies the reason for pruning the flow to the
indicated VLAN:
• Prune: A neighbor multicast router has sent a prune
request.
• Assert: Another multicast router connected to the
same VLAN has been elected to provide the path for
the specified multicast group traffic.
• Other: Used where the VLAN is in the pruned state
for any reason other than the above two reasons
(such as no neighbors exist and no directly con-
nected multicast receivers have issued Joins).
ProCurve# show ip pim mroute 234.43.209.12 192.168.1.0
PIM IP Multicast Route Entry
Group Address : 234.43.209.12
Source Address : 192.168.1.0
Source Mask : 255.255.255.0
Metric : 20
Metric Pref : 1
Assert Timer : 3 min 54 sec
RP-Tree : Yes
DownStream Interfaces
VLAN Prune Reason
---- ----------- -
2 other
3 other
Figure 4-15. Example of PIM Mroute Listing for a Specific Multicast Flow
