PIM-SM (Sparse Mode)
Displaying PIM-SM Data and Configuration Settings
Displaying BSR Data
The router provides BSR information through both IP PIM and the running
configuration.
Displaying BSR Status and Configuration
Syntax: show ip pim bsr
Lists the identity, configuration, and time data of the
currently elected BSR for the domain, plus the BSR-candidate
configuration, the Candidate-RP configuration and the
supported multicast groups on the current router.
ProCurve(config)# show ip pim bsr
Status and Counters - PIM-SM Bootstrap Router Information
E-BSR Address : 10.10.10.2
E-BSR Priority : 0
E-BSR Hash Mask Length : 30
E-BSR Up Time : 53 mins
Next Bootstrap Message : 88 secs
C-BSR Admin Status : This system is a Candidate-BSR
C-BSR Address : 10.10.10.1
C-BSR Priority : 0
C-BSR Hash Mask Length : 30
C-BSR Message Interval : 60
C-BSR Source IP VLAN : 100
C-RP Admin Status : This system is a Candidate-RP
C-RP Address : 10.10.10.1
C-RP Hold Time : 150
C-RP Advertise Period : 60
C-RP Priority : 192
C-RP Source IP VLAN : 100
Group Address Group Mask
--------------- ---------------
224.0.0.0 240.0.0.0
229.0.1.0 255.255.255.0
239.100.128.0 255.255.128.0
Elected BSR for
the PIM-SM
Domain
Candidate-BSR
Configuration for
the Current
Routing Switch
Candidate-RP
Configuration for
the Current
Routing Switch
Multicast
Groups for which
the Current
Routing Switch
Is Configured as
a Candidate-RP
Figure 4-22. Example of Listing BSR Data for the Domain and the Immediate Router
