IP Routing Features
Configuring OSPF
Configuring OSPF
Feature Default Page
Enable IP Routing and Global OSPF Routing disabled 5-62
Changing the RFC 1583 OSPF Compliance Setting enabled 5-63
Assign the Routing Switch to OSPF Areas n/a 5-65
Assign VLANs and/or Subnets to Each Area n/a 5-69
External Route Redistribution disabled 5-73
Configure Ranges on an ABR To Reduce Advertising n/a 5-76
Use Administrative Distance To Influence Route Choices 5-79
Generate OSPF Traps enabled 5-80
Cost Per Interface 1 5-82
Dead Interval Per Interface 40 sec. 5-82
Hello Interval Per Interface 10 sec. 5-83
Priority Per interface 1 5-83
Retransmit Interval Per Interface 5 sec. 5-84
Transit Delay Per Interface 1 sec. 5-84
Password and MD5 Authentication disabled 5-86, 5-87
Virtual Link Configuration n/a 5-88
Dead Interval on a Virtual Link 40 sec. 5-91
Hello Interval on a Virtual Link 10 sec. 5-91
Retransmit Interval on a Virtual Link 5 sec. 5-92
Transit Delay on a Virtual Link 1 sec. 5-92
Password and MD5 Authentication on a Virtual Link disabled 5-94, 5-95
Displaying OSPF Information n/a 5-97
This section describes how to configure OSPF using the CLI interface.
5-43
