TallyGenicom Intelliprint 8008N Color Laser Printer User Guide
6-32
Cleaning the scanner glass, printer inside and transfer belt
cleaning roller
If there are vertical white lines on all the colors down the page then it is likely
that the laser windows has become contaminated with toner. If this is the case
then it is possible that the inside of the printer needs cleaning. To do this
follow the procedure below.
Cleaning the Transfer belt cleaning roller
z Checking and removing the Transfer belt cleaning roller cover
The transfer belt cleaning roller cover is shown below. Note that the cover is
secured by the 2 clips you should not be able to lift the cover without bending
the clips in the direction of the left and right arrows arrows. When you bend the
clips in you should hear the cover unclip from both sides. Note. It is important
also that they clip back into place when the cover is returned. Remove the cover.
The left and right arrows are highlighted below. The front arrow advises which
way to insert the cover.
z Removing and cleaning the transfer belt cleaning roller and area
below
Next remove the transfer belt cleaning roller by holding the handle. Using a dry
lint free cloth clean the contacts at the end. Clean the surface of the roller only
if badly contaminated. Note do not breathe in any toner.
