Chapter 5 Extended Features
5-3
5.2 Installing DRAM Memory DIMMS
1.
Ensure that the printer power switch is set to the OFF [O] position.
2.
Disconnect the power cord from the wall outlet.
3.
Remove 2 screws from the top and bottom edge of the controller bracket
and gently pull bracket towards you to remove from printer.
4.
Carefully insert a DRAM DIMM which is compatible with your printer
into DRAM DIMM slot as shown below. When properly seated, gently
push down on the DIMM until the side braces close onto the ends of the
DIMM.
