TallyGenicom Intelliprint 8008N Color Laser Printer User Guide
2-16
2.6.3 Fuser unit shipping parts
Remove the Fuser shipping parts as illstrated below.
1. Pull the lever on the back cover to
unlock the back cover, and open
the back cover until it stops.
X Keep the back cover fully open
during the replacement work.
2. Pull the shipping release tabs
(orange colored) provided on the
left and right side of fuser unit
Each tab has a clip at the end which
was installed in the fuser for ship-
ping.
3. Close the back cover and push it
until it locks.
X Keep supporting the back cover as
you close it.
Back cover
Lever
Fuser unit
