114 Chapter 7 Printer options and consumables EN
Identifying consumables
The following illustrations show the location of the consumables.
Consumable locations *
* See “Approximate replacement intervals for consumable items” on page 102.
1 Toner cartridges 4 Transfer roller
2 Imaging drum cartridge 5 Air filters
3 Intermediate transfer belt 6 Fuser
6
5
3
1
2
4
