2-2 Configure Printing
Configure Printing The printer can print in several different modes for the combina-
tion of quality, resolution, and speed that you require.
Jet replacement refers to the printer’s ability to locate and
replace inkjets that are clogged or misfiring. High Quality mode
has the best jet replacement, Billboard Quality mode has the
highest speed, but without jet replacement.
The current print mode is shown in the top center of the control
panel. To change the print mode, follow these instructions.
1. On the control panel, press the Print Mode key.
The print mode menu appears, with these options
:
• Billboard Quality
• Production Quality
• High Quality
2. Press a print mode to select it.
A menu appears with these options:
• Bidirectional
• Unidirectional - Print From User to Service Side
• Unidirectional - Print From Service to User Side
The printer can print in both directions (bidirectional) or in
one direction only (unidirectional). Unidirectional printing can
Mode
Maximum Speed
(bidirectional printing)
Jet
Replacement
Billboard Quality
with 600x300 dpi jobs 811 sq. ft/hr (74.3 sq. m/hr) No
with 600x600 dpi jobs 438 sq. ft/hr (40.7 sq. m/hr) No
Production Quality
with 600x300 dpi jobs 438 sq. ft/hr (40.7 sq. m/hr) Yes
with 600x600 dpi jobs 225 sq. ft/hr (20.9 sq. m/hr) Yes
High Quality
with 600x300 dpi jobs 225 sq. ft/hr (20.9 sq. m/hr) Yes
with 600x600 dpi jobs 112 sq. ft/hr (10.4 sq. m/hr) Yes
