Manual Calibrations 4-23
Tip To avoid cutting the 10-inch (250 mm) pattern from
the media web, copy the marks from the printed pat-
tern to the long edge of a letter-size (or A4) sheet of
paper. Then measure the transferred marks and
adjust the media advance as needed until the marks
are exactly 10 inches (250 mm) apart.
Tip Run the 34-inch or 10-inch calibration first, then run
the stitch pattern version to fine-tune the media
advance accuracy.
Input MFN — enter the Media Feed Number that was dis-
played after a previous media feed calibration, to return to
that setting without performing the calibration again.
Print Jet-Out Lines This option prints a version of the Prime Bars in which missing
jets that are replaced are marked with a black square.
Default Registration Data This option resets all registration data. Since there is no registra-
tion data after running this option, all calibration values must be
reestablished by running the calibrations.
