12
www.honeywell.com/sensing
GLS Series
Global Limit
Switches
GLOBAL LIMIT SWITCHES
SPDT DPDT SPDT DPDT SPDT DPDT SPDT DPDT SPDT DPDT SPDT DPDT SPDT DPDT
EN50041
(GLA)
EN50047
(GLC, GLD,
GLE)
0,120 N m
(1.10 lb in)
0,165 N m
(1.50 lb in)
GLE only
11.5˚ 8˚
EN50041
(GLA)
EN50047
(GLC, GLD,
GLE)
16,0 N
(3.60 lb)
13,0 N
(2.90 lb)
GLE only
0,9 mm
(0.035 in)
0,6 mm
(0.024 in)
EN50041
(GLA)
EN50047
(GLC, GLD,
GLE)
16,0 N
(3.60 lb)
13,0 N
(2.90 lb)
GLE only
0,9 mm
(0.035 in)
0,6 mm
(0.024 in)
EN50041
(GLA)
EN50047
(GLC, GLD,
GLE)
11,0 N
(2.4 lb)
9,0 N
(1.9 lb)
GLE only
EN50041
(GLA)
EN50047
(GLC, GLD,
GLE)
1,3 N
(0.29 lb)
1,1 N
(0.25 lb)
GLE only
10˚ 7˚
Actuator
type
Body
size
26˚
35,8 mm
(1.41 in)
61,0 mm
(2.40 in)
28,0 mm
(1.10 in)
48,0 mm
(1.89 in)
18,0 mm
(0.71 in)
35,0 mm
(1.38 in)
4,5 mm
(0.18 in)
__
__
59˚
49˚
0,9 mm
(0.035 in)
12˚
0,9 mm
(0.035 in)
1,7 mm
(0.067 in
1,3 mm
(0.19 in)
8˚
16˚
18˚
3,0 mm
(0.12 in)
3,0 mm
(0.12 in)
__
4,5 mm
(0.18 in)
9,0 mm
(0.35 in)
__
5,2 mm
(0.205 in)
2,5 mm
(0.10 in)
3,0 mm
(0.12 in)
4,2 mm
(0.165 in)
3,45 mm
(0.14 in)
Overtravel
(OT)
Differential travel
(DT)
Operating point
(OP)
Top roller
lever
D
Lever types
A,
A*A, A*B,
A4J
Top pin
plunger
B
Top roller
plunger
C
Operating torque/force
(OF)
Pretravel
(PT)
0,330 N m
(2.90 lb in)
Wobble head
E7B, E7D,
K8B, K8C
16,0 N
(3.60 lb)
16,0 N
3.60 lb
9,5 N
(2.10 lb)
0,1 N
(0.90 in lb)
Free position
(FP)
Travel to
positive opening
(PO)
0˚ 55˚26˚
37,5 mm
(1.48 in)
21,0 mm
(0.83 in)
4,5 mm
(0.18 in)
5,0 mm
(0.20 in)
2,5 mm
(0.10 in)
3,0 mm
(0.12 in)
50,5 mm
(2.00 in)
31,0 mm
(1.22 in)
0˚
65,2 mm
(2.57 in)
39,25 mm
(1.55 in)
__
__
4,5 mm
(0.18 in)
5,0 mm
(0.20 in)
8,3 mm
(0.33 in)
6,9 mm
(0.27 in)
Operating characteristics
IEC947-5-1/EN60947-5-1
Designation & Rated operational current Ie (A) VA
Utilization Category at rated operational voltage Ue rating
120V 240V 380V 480V 500V 600V Make Break
AC15 A600 6 3 1.9 1.5 1.4 1.2 7200 720
AC15 A300 6 3 - - - - 7200 720
AC15 B300 3 1.5 - - - - 3600 360
AC14 D300 0.6 0.3 - - - - 432 72
125V 250V
DC13 Q300 0.55 0.27 69 69
DC13 R300 0.22 0.1 28 28
Electrical ratings
GLS Series switches offer a complete range of CENELEC approved products,
and are suitable for most industrial applications.
The standard product EN 50041 norm defines the switch mounting centres as
30 mm x 60 mm and also defines the switching characteristics of the side
rotary head with fixed lever, top pin plunger and top roller plunger. This means
that the switch can be interchanged in the application with other EN 50041
switches with mounting and switching characteristics maintained. Honeywell
offers many more head styles and switching options.
The miniature EN 50047 product range offers the user a choice of plastic,
metal and three conduit versions which are all mounting (20 mm x 22 mm)
compatible with each other. The EN 50047 standard defines how the switches
are mounted and the switching characteristics for fixed side rotary lever, top
pin plunger and top roller plunger.
Switching options:
SPDT Single Pole, Double Throw, Snap action contacts (1NC/1NO)
13
14
21
22
DPDT Double Pole, Double Throw Snap action contacts (2NC/2NO)
13
14
12
11
23
21
24
22
Actuators
