Service Calibrations
5-12
HP DesignJet 5000 and 5500 Series Printers Service Manual
2. If the correct media is loaded, the following message is displayed.
Press Enter to confirm or Back to return to the Service Calibrations
menu.
3. Once the media is detected, the calibration starts and the following
message is displayed:
During this stage the Printer will print the following pattern.
4. On completing the Line Sensor to Black Printhead calibration, the
following message is displayed:
2.2 Service Station
Top
Enter
Back
n
p
Press ENTER to confirm or
BACK to correct
Make Selection
Line Sensor to Black Pen
Calibrating
Drop Detector
Calibrating...
