HP DesignJet 5000 and 5500 Series Printers Service Manual
3. If media is not loaded, the following message appears on the front
panel and you must load media into the Printer. Press the Load/
Unload Media button (see the User’s Guide for detailed
information on loading media).
NOTE Do NOT use any other type of media apart from HP High Gloss
Photo Paper.
4. The Printer will start to print the Accuracy Calibration Pattern and
the following message will be displayed on the front panel:
Below is a sample of the pattern printed.
5. Once the Accuracy Calibration Pattern is completed, the following
message will be displayed. Select "Measure Pattern" and press
Enter to automatically start the Load/Unload Media procedure.
ACCURACY
calibration
Load media for
ACCURACY
Calibrating
Recalibrate
Top
Enter
Back
n
p
Press Enter
Make Selection
Create Pattern
Measure Pattern
